Enameled Aluminum Wire
Enameled Round Aluminum Wire
Diameter Range (mm): 0.3-6.5;
Diameter Range：AWG2- AWG32, SWG3-SWG35
Thermal Class: 130C, 155C, 180C, 200C, 220C
Standard: IEC, NEMA, GB, JIS
UL No:E338133
Package: PT25, PT30, PT60，PT90，PT200
Package:Wooden spool and according to customers requirements.
 Aluminum Wire.jpg)
Enameled Rectangular(flat) Aluminum Wire
Diameter Range (mm): thickness: 0.80-5.60mm width: 2.00-16.00mm
Width/thickness ratio:1.4<w/t<8.0
Thermal Class: 130C, 155C, 180C, 200C, 220C
Standard: IEC, NEMA, GB, JIS
UL No:E338133
Package: Plastic spool, Wooden spool and according to customers requirements.
Enameled Square Aluminum Wiree
Diameter Range (mm): thickness: 3.264-5.19mm width: 3.264-5.19mm
Diameter Range :AWG 4 -AWG 8
Thermal Class: 130C, 155C, 180C, 200C, 220C
Standard: IEC, NEMA, GB, JIS
UL No:E338133
Package: Wooden spool and according to customers requirements.
